Specifications
Details | |
---|---|
Product code | RBwAPG-5HacT2HnD-BE |
Architecture | MIPSBE |
CPU | QCA9556 |
CPU core count | 1 |
CPU nominal frequency | 720 MHz |
Dimensions | 185 x 85 x 30 mm |
RouterOS license | 4 |
Operating System | RouterOS |
Size of RAM | 64 MB |
Storage size | 16 MB |
Storage type | FLASH |
MTBF | Approximately 100'000 hours at 25C |
Tested ambient temperature | -40°C to 70°C |
Wireless capabilities
Details | |
---|---|
Wireless 2.4 GHz Max data rate | 300 Mbit/s |
Wireless 2.4 GHz number of chains | 2 |
Wireless 2.4 GHz standards | 802.11b/g/n |
Antenna gain dBi for 2.4 GHz | 2 |
Wireless 2.4 GHz chip model | QCA9556 |
Wireless 2.4 GHz generation | Wi-Fi 4 |
Wireless 5 GHz Max data rate | 1300 Mbit/s |
Wireless 5 GHz number of chains | 3 |
Wireless 5 GHz standards | 802.11a/n/ac |
Antenna gain dBi for 5 GHz | 2 |
Wireless 5 GHz chip model | QCA9880 |
Wireless 5 GHz generation | Wi-Fi 5 |
AC speed | AC1600 |
Ethernet
Details | |
---|---|
10/100/1000 Ethernet ports | 1 |
Powering
Details | |
---|---|
Number of DC inputs | 1 (PoE-IN) |
Max power consumption | 12 W |
Cooling type | Passive |
PoE in | 802.3af/at |
PoE in input Voltage | 11-57 V |
