MikroTik CSS610-8G-2S+IN

CHF118.91
Tax included

Switch 8 PORTS GB ETHERNET + 2X SFP+ 10GB/

Add to Cart
Reference CSS610 Category Switchs Brand MikroTik
Out-of-Stock
Facebook Twitter Pinterest

CSS610-8G-2S+IN

Cloud Smart Switch 610-8G-2S+IN is Mikrotiks answer to the everlasting demand for more power in a small and simple package. It comes with the lightweight SwOS which is easy to configure from your web browser. It gives you all the basic functionality for a managed switch, and more: you can manage port-to-port forwarding, broadcast storm control, apply MAC filters, configure VLANs, mirror traffic, apply bandwidth limitation and even adjust some MAC and IP header fields.

included parts: 24V 0.8A power adapter, K-48 fastening set, Rack ears for CSS610-8G-2S+IN

Specifications

Details
Product code CSS610-8G-2S+IN
Architecture 88E6193XA0-BXB2C000
CPU 88E6193XA0-BXB2C000
Dimensions 200 x 167 x 46 mm
Operating System SwitchOS
Storage size 64 KB
Storage type FLASH
Tested ambient temperature -20°C to 60°C


Powering

Details
PoE in Passive PoE
PoE in input Voltage 12-57 V
Number of DC inputs 2 (DC jack, PoE-IN)
DC jack input Voltage 12-57 V
Max power consumption 11 W
Max power consumption without attachments 5 W
FAN count Passive

Ethernet

Details
10/100/1000 Ethernet ports 8

Fiber

Details
SFP+ ports 2

Certification & Approvals

Details
Certification CE, EAC, ROHS

-

Switching results

CSS610-8G-2S+IN
Mode Configuration 1518 byte 512 byte 64 byte
kpps Mbps kpps Mbps kpps Mbps
Switching Non blocking Layer 2 throughput 2,275.7 27,635.9 6,578.9 26,947.4 41,666.7 21,333.3
Switching Non blocking Layer 2 capacity 2,275.7 55,271.8 6,578.9 53,894.7 41,666.7 42,666.7
Switching Non blocking Layer 1 throughput 2,275.7 28,000.0 6,578.9 28,000.0 41,666.7 28,000.0
Switching Non blocking Layer 1 capacity 2,275.7 56,000.0 6,578.9 56,000.0 41,666.7 56,000.0
